Dialog Boxes

People talk to other people and exchange their inputs via verbal dialogs. Dialog boxes are the medium to talk to its users and collect their inputs. A dialog box usually contains one or more controls/widgets with which the user enters text, chooses options, or directs the action of the command. Dialog boxes are primarily of two types - modal and modeless.

Modal dialogs

Modal dialog creates an UI thread and pops above parent window. This dialog gets curser focus on top of parent window and completely blocks parent. Parent windows cannot get focus until dialog closes. About box of any application is a good example of modal dialog.

About box Modal Dialog

DialogBox

DialogBox function which is basically a macro creates a modal dialog box from a dialog box template resource. DialogBox does not return control until the specified callback function terminates the modal dialog box by calling the EndDialog function. The DialogBox macro uses the DialogBoxParam function.

DialogBox API

int DialogBox(
  HINSTANCE hInstance,  /* handle to application instance */
  LPCTSTR lpTemplate,   /* identifies dialog box template */
  HWND hWndParent,      /* handle to owner window */
  DLGPROC lpDialogFunc  /* pointer to dialog box procedure */
);
int DialogBoxParam(
  HINSTANCE hInstance,     /* handle to application instance */
10    LPCTSTR lpTemplateName,  /* identifies dialog box template */
11    HWND hWndParent,         /* handle to owner window */
12    DLGPROC lpDialogFunc,    /* pointer to dialog box procedure */
13    LPARAM dwInitParam       /* dialog initialization parameter */
14  );

Modeless dialogs

Modeless dialog is one which opens on top of parent window but still parent can get focus and process events. Modeless dialog does not block parent window and this is needed when users need to enter frequent inputs and same time want to get the reflection in the parent window. Find/Replace dialog is a good example of modeless dialog.

Find Modeless Dialog

CreateDialog

CreateDialog macro creates a modeless dialog box from a dialog box template resource. The CreateDialog macro uses the CreateDialogParam function.

CreateDialog API

HWND CreateDialog(
  HINSTANCE hInstance,  /* handle to application instance */
  LPCTSTR lpTemplate,   /* identifies dialog box template name */
  HWND hWndParent,      /* handle to owner window */
  DLGPROC lpDialogFunc  /* pointer to dialog box procedure */
);
HWND WINAPI CreateDialogParam(
  HINSTANCE hInstance,         /* handle to application instance */
  LPCTSTR lpTemplateName,      /* identifies dialog box template name */
10    HWND hWndParent,             /* handle to owner window */
11    DLGPROC lpDialogFunc,        /* handle to owner window */
12    LPARAM dwInitParam           /* dialog initialization parameter */
13  );
